The ANYCUBIC Photon Mono M7 MAX has emerged as a revolutionary player in the resin 3D printing landscape, catering to both professional users and dedicated hobbyists. With an expansive print volume of 14.7 liters, this printer is designed for those who demand both speed and precision in their projects. It features an ultra-fast 4-second layer print speed, making it one of the fastest resin printers available today.
Equipped with a 7K resolution LCD and the innovative LighTurbo 3.0 High-Precision Light Source System, the M7 MAX delivers exceptional detail and accuracy in every print. This model builds upon its predecessors by offering improved speeds, larger print capacity, and smart automation features that streamline the printing process. In this ANYCUBIC Photon Mono M7 MAX Review, we will delve into the printer’s specifications, performance, usability, and overall value to help you determine if it is the right fit for your 3D printing needs.
Verdict
The ANYCUBIC Photon Mono M7 MAX is a robust and feature-rich resin printer that excels in speed and size. However, some users have reported concerns regarding the resin heating system, which may impact performance for specific applications.
Related: ANYCUBIC Photon Mono 4: Is This the Ultimate 10K Resin 3D Printer for $169?
ANYCUBIC Photon Mono M7 MAX Review
Pros & Cons
Pros
- Large Print Volume: The 14.7L capacity is ideal for large-scale projects.
- High-Speed Printing: Achieves a remarkable speed of 4 seconds per layer.
- Intelligent Release 2.0: This feature enhances print success rates by adjusting lifting heights dynamically.
- High Resolution: The 7K resolution ensures fine detail and precision in prints.
- Efficient Resin Management: Auto-recycling and level monitoring minimize waste.
- User-Friendly Design: The flip-open cover allows for easy access during operation.
- Multi-Device Sync: Compatible with cloud printing and multiple devices.
Cons
- Heating System Limitations: The resin heating system only preheats without maintaining temperature throughout the printing process.
- Auto-Resin Feeder Issues: Some users report difficulties with detecting low resin levels.
- Manual Leveling Requirement: The 4-point manual leveling system requires initial calibration.
ANYCUBIC Photon Mono M7 MAX Specs
| Specification | Details |
|---|---|
| Build Volume | 298mm x 164mm x 300mm |
| Printing Volume | 14.7L |
| Build Platform | Laser engraving aluminum alloy |
| Operating Screen | 4.3″ Touch-Control |
| LCD Screen Size | 13.6″, 7K |
| Resin Vat | 1.3L Unibody design with scale lines |
| Antenna Port | Yes |
| Light Source | COB light source + front-facing reflectors + Fresnel Lens |
| Light Uniformity | ≥90% |
| Light Intensity | 4500 ± 500 μW/cm² |
| Machine Leveling | 4-point manual leveling |
| XY Resolution | 46μm x 46μm |
| Z Axis | Double liners with 10μm accuracy |
| Slicing Software | Anycubic Slicing, CHITU & Lychee (support expected by end of December) |
| File Transfer | USB & WiFi, LAN (support expected around Q4 2024) |
| Release Film | ACF Film |
| Power Supply | 180W rated power |
| Anycubic App Support | Yes |
| Weight | Machine: 24kg / 52.91 lbs, Package: 28.5kg / 62.83 lbs |
| Size | Machine Dimensions: 425mm x 362mm x 652mm, Package Dimensions: 785mm x 520mm x 490mm |
| Hinged Cover | Effectively blocks UV radiation; supports one-hand opening at angles greater than 45° |
| Printing Speed | Max Speed ≤31mm/h (0.05mm layer with standard resin); Max Speed ≤63mm/h (0.1mm layer with standard resin); Max Speed ≤86mm/h (0.1mm layer with high-speed resin) |
| Support Languages | English, Chinese, German, French, Italian, Spanish, Russian, Japanese |
| Material Compatibility | Compatible with various resins (high speed, water-washable, standard, ABS-like, plant-based, etc.) |
| Protection Film | Replaceable anti-scratch film |
| Air Purifier Connection | USB |
Key Features & Performance
Print Speed & Resolution
The ANYCUBIC Photon Mono M7 MAX stands out with its ability to print at speeds of up to 86mm/h, particularly when using high-speed resin. The printer boasts a fine 46µm XY resolution, which translates to high-quality prints with intricate details.
Light Source Technology
The advanced LighTurbo 3.0 light source ensures consistent exposure across the print surface, contributing to the overall precision of each layer printed. This technology plays a crucial role in achieving uniformity throughout larger prints.
Intelligent Release Technology
The Intelligent Release 2.0 system dynamically adjusts the lifting height during the printing process, significantly improving success rates by reducing the risk of failed prints due to adhesion issues.
Resin Management System
The printer’s auto-recycling system works in conjunction with resin level monitoring to optimize material usage, making it more efficient and environmentally friendly.
Unboxing & What’s Included
When you unbox the ANYCUBIC Photon Mono M7 MAX, you will find:
- Photon Mono M7 Max
- Print Platform * 1
- Resin Vat * 1
- Scrapers * 2
- Hex Key Set
- Leveling Paper
- Manual * 1
- Cap part of auto-fill unit
- Protective Equipment
- Filter
- Antenna
- USB Drive * 1
- Power Cord
This comprehensive package ensures that you have everything needed to get started on your printing journey immediately.
Setup & Calibration
Assembly Process
Setting up the ANYCUBIC Photon Mono M7 MAX is straightforward, requiring minimal assembly effort. Most users can have it ready for operation within a short time frame.
Leveling Procedure
The printer utilizes a simple 4-point manual leveling system that allows users to calibrate the build platform easily. While this requires some initial setup, it is user-friendly enough for beginners.
Connectivity Options
The M7 MAX supports USB connectivity and WiFi capabilities. Notably, LAN support is expected to be introduced in Q4 2024, enhancing connectivity options further.
Design & Build Quality
Dimensions & Weight
With dimensions of 425mm x 362mm x 652mm and a weight of approximately 24kg, this printer is substantial yet manageable for most workspaces.
Design Features
The design includes a flip-open cover that provides UV protection while allowing easy access to the print area. This thoughtful design feature enhances user experience during operation.
Build Quality Assessment
Constructed from solid aluminum alloy and premium materials, the build quality of the ANYCUBIC Photon Mono M7 MAX ensures durability and stability during use.
Printing Performance & Sample Prints
Detail & Quality Analysis
Thanks to its 7K LCD, the printer produces high-detail prints that are suitable for professional applications such as prototyping or intricate model creation.
Speed Comparison
Achieving speeds of up to 86mm/h, this model outperforms many competitors in terms of build volume. However, it slightly lags behind models like the M7 Pro in terms of LCD resolution (14K).
Software & Slicer Compatibility
Native Software Features
The ANYCUBIC Photon Workshop software comes pre-installed with automated support generation and cloud slicing capabilities, making it easier for users to prepare their files for printing.
Third-Party Software Support
In addition to its native software, the printer is compatible with popular third-party slicers such as CHITUBOX and Lychee Slicer, providing flexibility for users who prefer different software environments.
Maintenance & Cleaning
Resin Handling Efficiency
With features like easy monitoring and an auto-recycling system, managing resin becomes less cumbersome, reducing waste significantly during operation.
Cleaning Procedures
Built-in resin residue detection simplifies cleaning processes post-printing, ensuring that users can maintain their equipment without excessive effort.
Component Replacement Ease
Accessing components such as film and screen protection is straightforward, allowing users to perform maintenance tasks without hassle.
Comparison With Predecessors
| Picture |  |  |  |
| Printer Model | Photon Mono M7 Max | Photon Mono M7 Pro | Photon Mono M7 |
| Suggested Retail Price | $999.99 | $699.99 | $649.99 |
| Build Volume | 298mm x 164mm x 300mm （14.7L） | 223*126*230mm | 223*126*230mm |
| Printing Speed | Standard Resin 0.05mm layer height: ≤31mm/h peek speed | Standard Resin 0.1mm layer height: ≤63mm/h peek speed | High Speed Resin 0.1mm layer height: ≤86mm/h peek speed | Standard Resin 0.1mm layer height: 130mm/h peek speed | High Speed Resin 0.1mm layer height: 170mm/h peek speed | Standard Resin 0.1mm layer height: 90mm/h peek speed | High Speed Resin 0.1mm layer height: 150mm/h peek speed |
| Layer Height | 0.01-0.15mm | 0.01-0.15mm | 0.01-0.15mm |
| LCD Screen | 13.6-inch Mono LCD | 10.1-inch Mono LCD | 10.1-inch Mono LCD |
| LCD Resolution | 7K | 14K | 14K |
| X/Y Axis Resolution | 46*46μm | 16.8*24.8μm | 16.8*24.8μm |
| Light Source | COB light source+ Fresnel lens+Light uniformity algorithm | COB light source+ Fresnel lens+Light uniformity algorithm | COB light source+ Fresnel lens+Light uniformity algorithm |
| Light Uniformity | ≥ 90% | ≥ 90% | ≥ 90% |
| Light Intensity | 4500±10%μW/cm² | 5500±10%μW/cm² | 4500±10%μW/cm² |
| Release Film | Improved ACF film | Improved ACF film | Improved ACF film |
| Intelligence Assisted Printing System | √ | √ | √ |
| Air vent | √ | √ | √ |
| Dynamic temperature control resin vat | √ | √ | × |
| Resin Auto-Fill Unit | √ | √ | × |
| Display Screen | 4.3-inch colored control screen | 4.3-inch colored control screen | 4.3-inch colored control screen |
| Anycubic App | √ | √ | √ |
| Machine leveling | 4-point manual leveling | Leveling-free | Leveling-free |
| Slicing Software | Photon Workshop & Chitubox & Lycheeslicer（Q4） | Photon Workshop & Chitubox & Lycheeslicer | Photon Workshop & Chitubox & Lycheeslicer |
| File Transfer | USB & WiFi & LAN MODE（2025 Q1） | USB & WiFi & LAN MODE（2025 Q1） | USB & WiFi & LAN MODE（2025 Q1） |
| Product Dimensions | 425*362*652mm | 312*315*520mm | 312*315*520mm |
| Packaging Dimensions | 785*520*490mm | 620*395*395mm | 620*395*395mm |
| Net Weight | 24KG | 12.8KG | 12KG |
Price & Value for Money
Pricing Overview
The ANYCUBIC Photon Mono M7 MAX is priced at approximately $999.99, positioning it as a premium option compared to other models like the M7 Pro at $699.99 and Mono M7 at $649.99.
Target Audience
This printer is designed for professionals and serious hobbyists who require high-speed printing capabilities along with large-volume production capabilities.
Tips for Optimizing Your Printing Experience
To maximize your experience with the ANYCUBIC Photon Mono M7 MAX:
- Regularly calibrate your printer to ensure optimal performance.
- Experiment with different resins to find one that suits your specific needs best.
- Utilize cloud slicing features for efficient workflow management.
- Keep your workspace clean to prevent contamination of resin materials.
Conclusion & Final Verdict
In conclusion, the ANYCUBIC Photon Mono M7 MAX stands out as an excellent choice for users who prioritize speed, precision, and large print volumes in their projects. While there are some drawbacks related to the resin heating system and auto-feeding issues reported by certain users, its impressive print quality and efficiency make it a valuable investment for serious resin printing enthusiasts.
Final Rating: 4.5/5
ANYCUBIC Photon Mono M7 Max
7K Resin
-  Maximum print speed of 4 seconds per layer (0.05mm layer height)
- LighTurbo 3.0 High-Precision Light Source System
- Intelligent Release 2.0 Precision Control
- 14.7L Ultra-Large Print Volume
- 20-40°C Resin Temperature Control with Resin Auto-Recycling Management
- 8 User-Friendly Improvements
Frequently Bought Together
ANYCUBIC 3D Printer Resin Bundle
For All LCD/DLP Printers
- High Precision: Designed for exceptional detail in LCD and DLP 3D printing.
- Quick Curing: Fast curing times enhance productivity.
- Excellent Fluidity: Ensures smooth flow during printing for better results.
- Compatible with 405nm Wavelength: Specifically formulated for use with 405nm SLA printers.
- Pack Size: Available in 4 packs of 1kg each, totaling 4kg.
- Color: Grey resin provides a versatile option for various applications.
ANYCUBIC Wash and Cure 3 Plus Station
Better Curing Effect
- Gooseneck Light: Provides targeted illumination for effective curing.
- Dual-Layer Design: Enhances efficiency and functionality during the washing and curing process.
- IPA Saving Technology: Optimizes isopropyl alcohol usage to reduce waste.
- Compatibility: Suitable for ANYCUBIC Photon Mono M5s, M7 Pro, Saturn, and other LCD/SLA/DLP 3D printers.
Frequently Asked Questions (FAQs)
What are the main differences between the ANYCUBIC Photon Mono M7 MAX and its predecessors?
The ANYCUBIC Photon Mono M7 MAX features a larger print volume of 14.7L, significantly increasing productivity by allowing users to print multiple models simultaneously. It also offers a faster print speed of 4 seconds per layer, enhanced 7K resolution, and the advanced Intelligent Release 2.0 technology for improved print success rates. Additionally, it includes a more sophisticated LighTurbo 3.0 High-Precision Light Source System for consistent exposure and better detail compared to earlier models like the M7 Pro and M7.
What type of resin should I use with the ANYCUBIC Photon Mono M7 MAX?
It is recommended to use high-speed resins specifically designed for LCD printers to achieve optimal results.
How do I maintain my ANYCUBIC Photon Mono M7 MAX?
Regularly check resin levels, clean after each use, and replace components as needed to ensure longevity.
Can I use third-party slicers?
Yes! The printer supports third-party slicers like CHITUBOX and Lychee Slicer for added flexibility in your workflow.
Is there a warranty on this printer?
Yes, ANYCUBIC typically offers a warranty on their printers; check their official website for specific details regarding coverage duration and conditions.
